Battleshield Fire Body

*** NEW BUILD ***

Pump & Roll

Pump House Overview

Waterous CSU 1250 GPM PTO/ 5000 LPM w/ Electric MIVs

Poly Armor painted – Frame and panels

40,000 BTU heater

Innovative Controls – Gauges and levers

Trident – Auto Prime on pump and 6” main intakes

FRC InControl pressure governor with control knob

FRC Tankvision water gauge

3/16" 5052-h32 Marine Grade Aluminum 1/8" 3003h22 Aluminum Checker Plate

AC, Power windows, mirrors and locks, AM/FM radio

Suspension:

Front: Taper leaf – maintenance free rubber bushings

Rear: Flat leaf spring – w/radius rod for Fire/Emergency service

Seats: Driver and passenger seats - H.O. Bostrom Sierra Air-30 High Back air

Custom 2 ½” to 1 ½” chrome caps

Black coated Storz fittings and caps

Marine grade 5052 3/16″ aluminum body sheet material, with 1/8″ aluminum checker overlays

Diamondback chassis steps and rear tailboard

Anodized Amdor roll-up doors with integrated full length Lumabars with pull tether cords

Aluminum folding ladder to access hose bed

FRC Maxvision water gauges – One (1) on each side of body and one (1) on rear

FRC InView reverse camera

Speaker mounted in front bumper

Pull out 500 lbs tray in L1, L4, R1, and L4 compartments

Heavy duty Vinyl cover on hose bed

Full NFPA graphics package w/ custom mural

Front and rear Chevron striping

Zico port-a-tank with suction hose tray

Zico ladder rack with suction hose tray

(2) 6” NH Hard Suction hoses w/long handles

(2) 10’ straight handle Pike poles

One set of rubber wheel chocks

(1) Truck first aid kit

(1) Emergency Triangle Kit

(1) 5lbs Dry Chemical ABC fire extinguisher
